The purpose of the signal converter SINEAX TV815 is to electrically insulate
input and output signals, respectively to amplify and / or change the signal
leverl or type (current or voltage) of the input signals.

Input: Pt100 (2, 3, 4 wires) (-150 °C...650 °C)
Output: Current 0/4...20 or 20...4/0 mA
or voltage 0...5/10, 10...0, 1...5 V DC
3-way galvanic isolation
Spring-cage clamp connection
Power bridging terminal ? DIN rail bus connector
Small dimensions (6.2 x 93.1 x 102.5 mm)
Resolution of 14 bit
Accuracy class 0.1%
