SINEAX 2i1

Name: SINEAX 2i1 | TECOSTORE.VN
Brand: Gossen Metrawatt
SKU: GM137
Availability: InStock
Rating: 5 (1 reviews)

Liên hệ

SKU: GM137 Danh mục: Chưa phân loại Thẻ: GM137 Gossen Metrawatt, Gossen Metrawatt Thương hiệu: Gossen Metrawatt

Mô tả
Thông số kỹ thuật

Signal isolator for electrically isolating an analog DC signal.
Functions as a passive isolator without external supply power and draws its
minimal energy requirements from the DC signal.

Measured quantity and measuring range can be programmed with a PC:
facilitates planning and project work, short lead-times, minimal inventory
Integrated cold junction compensation
Measuring transducer with 2-wire connection for field use in close
proximity to the process
Measurement output: 4 to 20 mA
Open-circuit sensor and short-circuit monitoring / defined output
performance in the event of disturbance
With or without auxiliary power terminals (prog. from 12 to 30V)
Small and compact for optimized space utilization
Available with "intrinsically safe" explosion protection per
EEx ia
IIC T6
Serial interface
K17 housing for top-hat rail mounting

SINEAX 2i1
