SSL 150 … 300

Measured Parameters

• (4) Differential Voltage: 16 bit resolution
  - 0-1000 Vrms, AC/DC, ± 0.1% reading ± 0.05% FS
  - IEC 61000-4-30 Class A:
     40-1000 Vrms, ± 0.1% of Udin, range of 10% ~ 150% of Udin
  - Transients – High Speed: 10-2000 Vpk, ± 10% of reading, ±
  0.5% FS
  - FS Transients – rms: 0-1400 Vpk, ± 0.2% of Udin

• (4) Current (rms): 512 s/c, 16 bit resolution
  - Range probe dep., AC/DC, ± 0.1% reading ± 0.05% FS, ±
  0.2% of Udin
  - Transients – High Speed: Range probe dep., 10% of Reading, ±
  0.5% FS
  - Transients – rms: Range probe dep., ± 0.2% of Udin

• Frequency: 10 sec window
  16-25 Hz, 41-69 Hz, ± 0.01 Hz

Calculated Parameters

• Power/Energy – 1 Second sampling
  Real Power (W) – P: meets 0.2S requirements, range probe dep.
  Apparent Power (VA) – S: meets 0.2S requirements, range probe dep.
  Reactive Power (var) – Q: meets 0.2S requirements, range probe dep.
  Power Factor (W / VA): -1 to 0 to +1
  Displacement cos &phi: -1 to 0 to +1
  Demand (in W): meets 0.2S requirements, range probe dep.
  Energy (in Wh): meets 0.2S requirements, range probe dep.

• Distortion – 200ms, 3 sec, 10 min windows
  V thd: 0-100%, ± 5% for V ≥ 1% Vnom,
  V Ind Harm: DC, 2-127, ± 5% for V ≥ 1% Vnom
  I thd: 0-100%, ± 5% for V ≥ 1% Vnom,
  I Ind Harm: DC, 2-63, ± 5% for V ≥ 1% Vnom

• Miscellaneous
  Pst – 10 minutes: 0.2-10, ± 0.05 @ Pst=1
  Plt – 2 hours: 0.2-10, ± 0.05 @ Pst=1


Standards Compliance

General Specifications

• Size (HxWxD): 207 x 256 x 67 mm
• Weight: 2 kg (4.3 lbs)
• Operating temperature: 0 to 50 °C
• Storage temperature: -20 to 60 °C
• Humidity: 0-95%, non condensing
• Clock accuracy and resolution:
  Internal ± 1 sec/day at 25 °C, NTP: ± 10 msec, GPS: ± 1 msec
• AC Adapter: 100-240 Vac 50/60Hz
• Battery capacity and charge time: 3 hours run time on full charge
• Memory size: 4GB
• Display: 7" WVGA color graphic, Icon based touch LCD, LED Backlit
• Languages: English, German, Spanish, French, Italian, Swedish, Finnish, Polish,
  Chinese (traditional and simplified), Thai, Korean
