POINTAX 6000M

POINTAX 6000M parameters can be freely selected, which allows for
adapting to a variety of measuring tasks for the logging of electrical
quantities and temperatures with PT 100 sensors or thermocouples.

Pressure and moisture, as well as other process quantities, are connected
via measuring transducers, and special characteristic curves can be implemented by means of user specific
linearization.

The POINTAX 6000M is available as a scale instrument with 1 to 6 scale graduations.

The entire plotting area can be used as a recording range, or separate
traces can be assigned to each individual channel. Recording direction can
be selected individually for each channel. Representation can be accomplished
in a linear fashion with one or two additional break points, or in a logarithmic
fashion. In addition, up to 4 event markers can be included in the chart.
